The Karcher HDS 7 10 4 M single phase HDS hot water high pressure cleaner reaches new levels of performance, reliability and economy. With innovative new features such as the ECO mode, this unit offers fuel savings of up to 20% without compromising cleaning performance. The new HDS range provides our customers with the toughness, cleaning power and low running costs they demand.

Features & Benefits:

• 4 pole, air-cooled electric motor with long life bearings
• 3 piston axial pump with ceramic pistons
• Machine protector chemical system protects against limescale
• 3 year heater coil warranty.
• User friendly control panel with LED warningand service display
• Service switch meters unit machine protector chemical and calls up service information
• ECO mode offering 20% fuel savings over previous models and full water flow at 60°C.
• New layout offering easy access to all service components and improved mobility
• Pivoting 1050mm stainless steel spray lance.
• Easy Press trigger gun prevents operator fatigue
• Low fuel cut-out facility.
• Motor protection switch to protect against overload.
• Flue gas temperature limiter switches off the drive motor if the flue gas exceeds 300ºC.

Standard accessories:

• Easy press trigger gun
• 10m High Pressure hose
• 1050mm Spray lance
• Power nozzle
• SDS system
• RM 110 Advanced Machine Protector

Technical Data:

• Power supply (Ph V Hz) 1 240 50
• Water flow rate (l h) 350 700
• Pressure (bar/MPa) 30 100 3 10
• Max. temperature (ºC) 155 80
• Connected load (kW) 3.4
• Consumption, fuel oil (ECO, max. 60ºC) (kg h) 3.4
• Fuel tank (l) 25
• Detergent tank (l) 20 + 10
• Weight (kg) 145
• Dimensions (L x W x H) (mm) 1330 x 750 x 1060
